Input (DC) |
Max. PV input voltage | 1000 V |
Min. PV input voltage / Startup input | 550 V / 570 V |
MPP voltage range for nominal power | 570 – 850 V |
No. of independent MPP inputs | 1 |
No. of DC inputs | 1, 8 – 12 |
Max. PV input current | 2000 A |
Max. DC short-circuit current | 2400 A |
PV array configuration | (Negative grounding (standard), positive grounding or floating (o ptional |
Output (AC) |
Nominal AC power (at 55 ˚C) | 1000 kW |
Max. AC output power at PF=1 (at 50 ˚C) | 1100 kW |
Max. AC apparent power (at 50 ˚C) | 1100 kVA |
Max. AC output current | 1650 A |
Nominal AC voltage | 385 V |
AC voltage range | 383 – 424 V |
THD | < 3 % (at nominal power) |
DC current injection | < 0.5 % In |
Power factor at nominal power / Adjustable power factor | > 0.99 / 0.8 leading – 0.8 lagging |
Feed-in phases / Connection phases | 3 / 3 |
Efficiency |
Max. efficiency / CEC efficiency | 98.8 % / 98.5 % |
Protection |
DC input protection | Load switch + fuse |
AC output protection | Circuit breaker |
Overvoltage protection | DC Type II / AC Type II |
Grid monitoring / Ground fault monitoring | Yes / Yes |
Overheat protection | Yes |
General Data |
Dimensions (W*H*D) | 102.3''*85.2''*39.4'' 2598*2164*1000 mm |
Weight | 4519.5 lb 2050 kg |
Isolation method | Transformerless |
Degree of protection | NEMA 3R |
Night power consumption | < 20 W |
Operating ambient temperature range | -22 to 140 ℉ (> 131 ℉ derating) -30 to 60 °C (> 55 °C derating) |
Allowable relative humidity range (non-condensing) | 0 – 95 % |
Cooling method | Temperature controlled forced air cooling |
Max. operating altitude | 13123 ft (> 6561 ft derating) 4000 m (> 2000 m derating) |
Display | Touch screen |
Communication | RS485, Ethernet |
Compliance | UL 1741, IEEE 1547, CSA C22.2 #107.1-01 |
Grid support | LVRT, HVRT, active & reactive power control and power ramp rate control |
Transformer |
