Efficient

  ▪ Integrated intelligent DC combiner and surge protection improve system flexibility and lower the system cost.

  ▪ Max efficiency is up to 98.9%, wide input voltage range, adapt to all kinds of solar panels and string configuration.

  ▪ Dual MPPTs work independently and allow unbalanced input power. One MPPT maximum input is up to 60% of Max. DC power.

  ▪ Adopt the latest technologies and combination of T-type three level topologies and SVPWM.

  ▪ Reactive power control and Power factor adjustable:0.8 leading~0.8 lagging.



  Reliable

  ▪ IP65 protection level, suitable for various installation environments.

  ▪ Bus capacitors consist of advanced film capacitors, designed with the latest thermal simulation technology for longer lifespan.

  ▪ Insurance by well-known international property insurance company (AIG) for Products /Completed Operations Liability Insurance.



  Smart

  ▪ AC output power is adjustable between 1-100%.

  ▪ Smart grid adaptive to meet the requirements of various power grid accesses.

  ▪ Variety of monitoring modes: APP (one-button registration), large screen data monitoring center, cloud monitoring platform.

  ▪ Support RS485,GPRS,WIFI, Ethernet.



  Simple

  ▪ High power density, small size.

  ▪ Modular design, easy to maintain.

(INPUT (DC
(Max. DC input power (W54300 // 66000
(Max. DC input voltage (V1100
(Starting voltage (V300/280
(Min. opration voltage (V300/280
(MPPT Range(V280 - 900
Number of MPPT2/5
String per MPPT2/5
Max. DC current (A) Per MPPT42x2
x Number of MPPT42x2
DC switchIntegrated
(OUTPUT (AC
(Rated output power (W50000 // 60000
(Max. AC output current(A52 // 57
Grid voltage range(3/N/PE,310/540V,(459~594V) // 3/N/PE,381/660V,(561~726V
Grid frequency range(50Hz (47~51.5Hz) / 60Hz (57~61.5Hz
Power factor-0.8~+0.8 (adjustable)
THDi< 3% (at rated power)
AC output(Three-phase (L1, L2, L3, N, PE)/(L1, L2, L3, PE
SYSTEM
Cooling methodSmart cooling method
Max.efficiency98.90%
Euro-efficiency98.60%
MPPT efficiency99.90%
Protection ratingIP65
(Self-consumption(at night) (W<0.5
TopologyTransformerless
Operating temperature range-25℃~+60℃(derate after 45℃)
Relative humidityPV array insulation protection, PV array leakage current protection, Ground fault monitoring // Grid monitoring, Island protection, DC monitoring, Short current protection etc.
DISPLAY AND COMMUNICATION
Display3.5inches LCD display, support backlit display
LCD languageEnglish, Chinese, German, Dutch
Communication interface(RS485 (standard) ;WiFi、Ethernet (optional)
MECHANICAL PARAMETERS
(Dimension(H x W x D mm645x660x225
(Weight(kg62
InstallationWall mounting
OTHERS
DC terminalMC4
Grid standardNB/T 32004-2013,TUV, CE, VDE0126-1-1,VDE-AR-N4105, G59/3,C10/11, TF3.2.1 // AS/NZS 4777.2:2015, EN61000-6-1:4, EN61000-11:12;IEC62109-1:2010, PEA,ZVRT
Safe certificateIEC 62109-1 :2010,IEC 62109-2 :2011,EN 61000-6-2: 2005
EMC categoryEN 61000-6-3:2007/A1:2011
(Factory warranty (years5
